This manual provides step‑by‑step installation instructions for the Southstar SR2 charge appliance, including placement, grounding, and connection details. It also describes the device’s operating modes, safety warnings, and LED indicator behavior.
Technical specifications such as supported frequency bands, power input voltage, and performance parameters are listed, along with guidance for troubleshooting and maintenance. This manual is written in Japanese.
| Power input voltage | DC12 V (optional DC5 V) |
|---|---|
| X‑BAND frequency | 10.525 GHz + 100 MHz |
| K‑BAND frequency | 24.150 GHz + 175 MHz |
| Ku‑BAND frequency | 24.125 GHz + 175 MHz |
| Ka‑BAND frequency | 34.700 GHz + 1300 MHz |
It requires a DC12 V power supply, with an optional DC5 V configuration.
