The Southstar NAVL868 is a multifunction satellite navigation device with built‑in radar, photo capture, and speed measurement features. It is designed for vehicle use and includes an electronic‑dog safety system.
The manual covers component lists, installation steps, power connections, GPS specifications, system configuration, and warranty information. It also explains how to set up the electronic‑dog mode, adjust radar sensitivity, and perform basic troubleshooting. This manual is written in Chinese.
| Dimensions | 125 mm (L) × ? mm (W) × ? mm (H) |
|---|---|
| Operating temperature | -10 °C to +60 °C |
| Storage temperature | -20 °C to +70 °C |
| Operating humidity | 45 % to 80 % RH |
| Storage humidity | 30 % to 90 % RH |
| Power supply | DC 12 V |
| USB power output | USB interface |
The device comes with a one‑year warranty from the date of purchase.
It can operate from –10 °C up to +60 °C.
The unit is powered by a DC 12 V source and also provides a USB power output for accessories.
Enter the electronic‑dog setup mode, then adjust radar sensitivity, speed thresholds, and warning messages as described in the manual.
