This guide introduces the features and functions of bourns smd pre-trimmed capacitors. Including various product sizes, packaging options, capacitance values, technology, adjustment methods, etc.
This guide presents a comprehensive overview of Bourns SMT trimming potentiometers, including product selection criteria, detailed specifications, optional accessories, and packaging options. It covers a wide range of models such as 3214*, 3224*, 3269*, 3302, 3303, and many others.
The document also details panel‑mounting options, adjustment tools, lab design kits, Mil‑Spec part numbering, application guidelines, and recommended soldering and cleaning processes, helping designers choose the right trimmer for their application. This manual is written in Chinese.
| Standard Resistance Range | 10 to 5 megohms |
|---|---|
| Resistance Tolerance | ±10 % std. |
| Temperature Range | -55 °C to +125 °C |
| Standard Packaging | 25 pcs per tube |
The 3006 trimmer has a standard resistance range of 10 to 5 megohms.
The resistance tolerance is ±10 % standard.
Standard packaging is 25 pieces per tube.
