3M Shielded Compact Ribbon (SCR) Connectors Wiremount Receptacle 362 Series Manual

3M 362 series Shielded Compact Ribbon (SCR) Wiremount Receptacle is the ideal mate for all 3M 3M™ Shielded Compact Ribbon (SCR) Boardmount and Wiremount Plugs, features robust ribbon style contact for reliable, repetitive plugging, 10 contacts can carry signal or power (up to one ampere per pin), has vibration resistant, solder termination for quick assembly with no dedicated tooling, accommodates up to 18AWG wire.

Brand
3M
File format
PDF
Published
09 April, 2012
Updated
30 September, 2023
MD5 checksum
D96873CA29DE8148903BE64E3C9C336E
PDF
3M Shielded Compact Ribbon (SCR) Connectors Wiremount Receptacle 362 Series Manual PDF
Download PDF
