This product is a 3M blue round conductor flat cable with model number 3601, 28 AWG wire, 0.050 inch pitch and excellent abrasion, chemical and mechanical durability. It meets UL certification and can work in temperature range from -55°C to +200°C.
The 3M 3601 Series round conductor flat cable features .050" pitch parallel conductors with 28 AWG stranded, FEP insulation, and a blue marking on one edge to designate wire #1. It offers low dielectric constant, excellent abrasion and chemical resistance, and is non‑flammable with UL recognition to 200 °C.
The sheet lists electrical characteristics such as 300 V USA rating, 131 Ω characteristic impedance, 9.9 pF/ft capacitance, 0.17 pH/ft inductance, and 1.29 ns/ft propagation delay, as well as environmental ratings from –55 °C to +200 °C. Regulatory appendices detail RoHS compliance and warranty information.
| Conductor size | 28 AWG, 7 × 0.127 mm Silver Plated Stranded Copper |
|---|---|
| Voltage rating (USA) | 300 V |
| Capacitance | 9.9 pF/ft |
| Inductance | 0.17 pH/ft |
| Propagation delay | 1.29 ns/ft |
| Temperature rating | -55 °C to +200 °C |
| Flammability rating | UL Recognized to 200 °C (VW‑1) |
The cable is rated for 300 V in the United States.
It can operate from –55 °C up to +200 °C.
Yes, the product is RoHS compliant according to EU Directive 2002/95/EC.
Wire #1 is identified by a blue marking on one edge of the cable.
