The MCP6071/2/4 family of operational amplifiers from Microchip Technology Inc. features low input offset voltage, rail-to-rail input and output operation, wide supply voltage range, and other characteristics. They are suitable for automotive, portable instrumentation, sensor conditioning, battery-powered systems, medical instrumentation, test equipment, and analog filters applications.
The MCP6071/2/4 family of operational amplifiers offers low input offset voltage (±150 µV max) and rail‑to‑rail input and output operation. Available in single (MCP6071), dual (MCP6072) and quad (MCP6074) configurations, the devices operate from a single supply as low as 1.8 V and draw only 110 µA typical quiescent current per amplifier.
Key specifications include a gain‑bandwidth product of 1.2 MHz (typical), unity‑gain stability, and an operating temperature range of –40 °C to +125 °C. The amplifiers are offered in SOIC, TDFN, and TSSOP packages and are suited for automotive, medical instrumentation, battery‑powered systems, and portable instrumentation applications.
| Input Offset Voltage | ±150 µV (max) |
|---|---|
| Supply Voltage Range | 1.8 V to 6.0 V |
| Gain Bandwidth Product | 1.2 MHz (typical) |
| Operating Temperature Range | -40 °C to +125 °C |
It operates from 1.8 V up to 6.0 V.
The family is offered in single (MCP6071), dual (MCP6072), and quad (MCP6074) configurations.
The typical gain‑bandwidth product is 1.2 MHz.
