3M™ Standard Style Heel Grounder is a grounder that connects the human body to the ground. It can effectively discharge static electricity from the human body by connecting the human body to the ground. This grounder uses nylon band with good conductivity, which ensures the durability of the product. 3M™ Standard Style Heel Grounder is a very practical grounder that can effectively solve the problem of static electricity.
The 3M Heel Grounder is a standard‑style ESD protective device that attaches to the heel of a shoe with a stretch‑nylon strap. It features a three‑layer rubber sole, a multi‑strand carbon‑suffused nylon ribbon, and a 1 megohm resistor to safely discharge static electricity.
The grounder complies with ANSI/ESD S‑20.20, EIA 625, MIL‑STD‑1686 and MIL‑HDBK‑263. It is UL listed, made in the USA, and designed for durability and cost‑effectiveness.
| Resistor | 1 megohm |
|---|---|
| Color | Black |
| Ribbon | Multi‑strand, carbon suffused nylon on polyester |
| Hook and Loop | 3/4" |
| Elastic Strap | Black |
| Sole Interior | Non‑marking |
| Sole Exterior | <10° ohms |
| Part Number | HGS1M |
The Heel Grounder uses a 1 megohm resistor.
It meets ANSI/ESD S‑20.20, EIA 625, MIL‑STD‑1686 and MIL‑HDBK‑263.
