This manual describes the functionality and use of the EV-OXU210-PCI evaluation board.
This guide describes the EV‑OXU210‑PCI Evaluation Board, a two‑board system that combines an EV‑OXU210 Evaluation Board with a 33 MHz, 32‑bit PCI104 Bridge Board. The board enables the EV‑OXU210HP device to be used in any PCI‑based computer, exposing the device through PCI memory space.
The manual covers PCI operation, configuration registers, serial EEPROM settings, power distribution, connector pinouts, and detailed schematics for both the evaluation board and the PCI104 bridge. It also includes board dimensions, mounting information, and test point locations.
| Vendor ID | 192E |
|---|---|
| Device ID | 032B |
| Class Code | 0680h |
| Board Thickness | Approximately one inch |
| PCI Bus Power | 3.3 V taken from PCI bus |
| PCI Bridge Chip | PLX9030 |
It allows the user to install and use the EV‑OXU210 in any PCI‑based computer, providing access to the OXU210HP via PCI memory space.
They are accessed by read/write operations to the PCI configuration space, which is separate from memory and I/O space.
Vendor ID is 192E and Device ID is 032B.
It requires space for two PCI devices but fits into a single PCI slot.
