9529 double-coated foam tape is a foam double-coated tape launched by 3M company. It is made of medium-firm rubber resin pressure sensitive adhesive, features good holding power, good high temperature and solvent resistance and adhesion to a wide variety of surfaces including low surface energy plastics such as polyethylene and polypropylene.
The 3M 9529 Double Coated Foam Tape is a medium‑firm, rubber‑resin adhesive tape with a polyethylene foam core. It offers good holding power on a wide variety of surfaces, including low‑surface‑energy plastics such as polyethylene and polypropylene. Key physical properties include a 1.50 mm tape thickness, 0.10 mm liner, and a total thickness of 1.60 mm.
Application techniques recommend clean, dry surfaces and an ideal temperature range of 21 °C to 38 °C. Use isopropyl alcohol for surface cleaning, and apply firm pressure for best bond strength. The tape is suitable for splicing paper, foil or film, mounting posters, nameplates, and manufacturing sample cards.
| Adhesive Type | Medium‑Firm Rubber Resin |
|---|---|
| Foam Density | 70 kg/m³ |
| Tape Thickness | 1.50 mm |
| Liner Thickness | 0.10 mm |
| Shelf Life | 12 months from date of despatch (stored at 21 °C, 50 % RH) |
| UV Light Resistance | Not recommended for direct exposure |
The ideal tape application temperature range is 21 °C to 38 °C (70 °F to 100 °F).
Surfaces must be clean, dry, and well unified; a typical cleaning solvent is isopropyl alcohol.
The tape has a shelf life of 12 months from the date of despatch when stored in the original carton at 21 °C and 50 % relative humidity.
No, it is not recommended for direct exposure to sunlight or other ultraviolet light sources.
