ADE5166/ADE5169/ADE5566/ADE5569 are single-phase energy measurement ICs with built-in 8052 MCU, RTC and LCD driver. They support wide voltage range supply (2.4V to 3.7V), internal bipolar switch between regulated and battery inputs, ultra-low power operation with power saving modes (PSM), including full operation mode, battery mode, sleep mode, real-time clock (RTC) mode and RTC and LCD mode.
The ADE5166, ADE5169, ADE5566 and ADE5569 are single‑phase energy‑measurement ICs that integrate an analog front‑end, a fixed‑function DSP, an 8052‑based MCU, a real‑time clock and an LCD driver in a single package. They support active, reactive and apparent energy calculations, RMS voltage and current measurements, and comply with IEC 62053‑21/22/23, EN 50470‑3 and ANSI C12‑16 standards.
The devices also include a 62 kB flash memory, 2.256 kB RAM, dual UARTs, SPI/PC interface, and LCD drivers (104‑segment for ADE5166/ADE5169, 108‑segment for ADE5566/ADE5569). Power‑saving modes, battery switchover, and extensive fault‑detection features enable low‑power operation for electronic energy meters.
| Supply voltage range | 2.4 V to 3.7 V |
|---|---|
| Operating temperature range | ‑40 °C to +85 °C |
| Active energy measurement error | 0.1 % of reading over a dynamic range of 1000 : 1 at 25 °C |
| Reactive energy measurement error | 0.5 % of reading over a dynamic range of 1000 : 1 at 25 °C |
| Flash memory size | 62 kB |
| On‑chip reference voltage | 1.2035 V |
They operate from 2.4 V to 3.7 V.
The active energy measurement error is 0.1 % of the reading over a dynamic range of 1000 : 1 at 25 °C.
The device includes 62 kB of flash memory.
