This document provides an assembly parts list for a humidity probe HMP45A/D, including nuts, washers, screws, etc. The humidity probe is shown from front, side, top, and bottom views. The product features M6 nuts, B6 spring washers, A6.4 washers, and more.
This document provides the operating instructions for the Vaisala DTR503 humidity probe. It includes multiple perspective drawings (bottom, front, side, and top views) to aid in proper installation and alignment.
The manual lists the required hardware components such as screws, nuts, washers, and spring washers, together with their DIN standards and quantities. Dimensional data for the pole mast and the probe model are also provided.
| Pole Mast Diameter | 30...60 mm |
|---|---|
| Probe Model | HMP45A/D |
| Screw M4x10 | DIN912, 2 pcs |
The humidity probe model is HMP45A/D.
The pole mast diameter ranges from 30 to 60 mm.
