TLE 6288 R is a smart 6-channel peak and hold switch with adjustable peak and hold current control and high/low side configurable features. It has protection features including over current, over temperature, and over voltage, as well as diagnostic functions. It is suitable for applications such as solenoids, relays, and resistive loads.
The TLE6288R Smart 6 Channel Peak&Hold Switch is a 6‑channel multichannel switch featuring adjustable peak and hold current control, over‑current, over‑temperature, over‑voltage and ESD protection. It supports 3.3 V and 5 V microcontrollers via a 16‑bit SPI interface and can drive solenoids, relays, valves and other inductive loads up to 10 kHz PWM.
The device offers configurable high‑side or low‑side operation for channels 4‑6, parallel and SPI control, and diagnostic outputs for each channel. Detailed electrical characteristics, pin assignments, and timing diagrams are provided for system integration.
| Supply voltage (VCC) | 4.5 – 5.5 V |
|---|---|
| On‑resistance (RON) | 0.15 Ω (typical) |
| Peak current range | 1.2 – 3.6 A |
| Hold current range | 0.7 – 2 A |
| Fixed off‑time range | 100 – 400 µs |
| Power supply current (standby) | 50 µA |
| Number of channels | 6 |
The device operates from a 4.5 V to 5.5 V supply.
It provides six independent channels.
Each channel can deliver a peak current between 1.2 A and 3.6 A.
Channels 4‑6 can be configured as either high‑side or low‑side switches via SPI.
