This is a technical documentation of Infineon Technologies ICE2A165/265/365 ICE2A180/280 Off-Line SMPS Current Mode Controller with integrated 650V/ 800V CoolMOS™
The CoolSET‑F2 is an off‑line SMPS current‑mode controller with integrated 650 V/800 V CoolMOS™ devices, offered in a P‑DIP‑8‑6 package. It targets low‑power standby applications and includes features such as auto‑restart, overload protection, and adjustable peak current limitation.
This datasheet contains pin configuration, block diagrams, functional description, electrical characteristics, typical performance data, and mechanical dimensions for the ICE2A165/265/365 and ICE2A180/280 part numbers.
| Package | P‑DIP‑8‑6 |
|---|---|
| Input Voltage Rating | 650 V / 800 V |
| Switching Frequency | 100 kHz |
| Maximum Duty Cycle | 72 % |
| Standby Current Consumption | max 55 µA |
| Current Limiting Tolerance | < +5 % |
It uses a plastic dual in‑line package (P‑DIP‑8‑6).
The controller operates at a switching frequency of 100 kHz.
In standby mode the device draws a maximum of 55 µA.
The device supports either 650 V or 800 V input, depending on the part number.
