Intel Socket 478 Processor Based Mainboard User Manual

This is the user manual of Intel Socket 478 Processor Based Mainboard

Brand: Intel
Category: Motherboard
Document type: User Manual
Language: English
Pages: 96
File format: PDF
File size: 6.4 MB
Published: 05 April, 2012
Updated: 30 September, 2023
Model: Socket 478
MD5 checksum: 33F0E052091D4A07E5AFA21CC601B3A9
PDF: Intel Socket 478 Processor Based Mainboard User Manual PDF

About this manual

This manual describes the Intel Socket 478 Processor Based Mainboard built around the Intel® 845PE chipset, which includes the MCH (FW82845PE), ICH4 (FW82801DB) and Firmware Hub components. The board supports AGP 4X, 266/333/333+ MHz DDR SDRAM, Ultra ATA/66/100, USB host controller, and a data transfer rate of 400/533/533+ MHz.

The document covers an introduction to the board, a detailed parts checklist, installation procedures, jumper settings, memory configuration, expansion slots, BIOS setup, power management, driver installation, and extensive troubleshooting information including POST codes and error solutions.

What's inside

Introduction
System Overview
Chipset Components
Mainboard Layout
Installation Procedure
Jumper Settings
Memory Configuration
Expansion Slots
Device Connectors
BIOS Setup

Specifications

Supported Memory Types	DDR‑200/266/333/333+ (PC1600/2100/2700)
Chipset	Intel® 845PE (MCH FW82845PE, ICH4 FW82801DB, FWH)
AGP Support	AGP 4X
Data Transfer Rate	400/533/533+ MHz
Storage Interface	Ultra ATA/66/100

Frequently asked questions

What should I do for an overclock error?

Clear the CMOS or press the insert key to power on the system.

Download PDF (6.4 MB)
