the max3372e-max3379e and max3390e-max3393e ±15kv ESD-protected level translators provide the level shifting necessary to allow data transfer in a multivoltage system.
The MAX3372E‑MAX3379E and MAX3390E‑MAX3393E families are +15kV ESD‑protected level translators that shift data between low‑voltage ASIC/PLD domains and higher‑voltage systems. They support bidirectional or unidirectional translation, three‑state output, and ultra‑low supply current.
Key features include guaranteed data‑rate options from 230 kbps up to 16 Mbps, operation down to +1.2 V on VL, thermal short‑circuit protection, and a variety of UCSP, SOT‑23‑8 and TSSOP packages. Electrical and timing characteristics are provided for each device variant.
| ESD protection | +15 kV |
|---|---|
| VCC supply range | 1.65 V to 5.5 V |
| Maximum data rate (MAX3372E/3377E) | 230 kbps |
| Package type (MAX3379E) | 14‑pin TSSOP |
They provide +15 kV ESD protection on the I/O VCC lines.
The MAX3372E operates at a guaranteed data rate of 230 kbps.
The MAX3372E is available in an 8‑pin SOT23‑8 package.
