The OP07D is a precision, ultralow offset amplifier. It integrates low power (1.1 mA typical), low input bias current (±1 nA maximum), and high CMRR/PSRR (130 dB) in the small DIP package. Operation is fully specified from ±5 V to ±15 V supply. The OP07D provides higher accuracy than industry-standard OP07-type amplifiers due to Analog Devices’ iPolar™ process, which supports enhanced performance in terms of offset, noise, and distortion.
The OP07D is a precision, ultra‑low offset amplifier that integrates low power (1.1 mA typical), low input bias current (1 nA max), and high CMRR/PSRR (115 dB min) in a small DIP or SOIC package. It operates from +4 V to +18 V and is specified over an industrial temperature range of –40 °C to +125 °C.
Key features include a maximum offset voltage of 150 pV, low voltage noise (0.28 µV p‑p from 0.1 Hz to 10 Hz), a gain‑bandwidth product of 0.6 MHz, and robust ESD protection. The datasheet provides detailed electrical specifications, pin configurations, typical performance curves, and absolute maximum ratings.
| Supply Voltage Range | +4 V to +18 V |
|---|---|
| CMRR (minimum) | 115 dB |
| PSRR (minimum) | 115 dB |
| Gain‑Bandwidth Product | 0.6 MHz |
| Voltage Noise (0.1 Hz‑10 Hz) | 0.28 µV p‑p |
It operates from +4 V up to +18 V.
The device provides a minimum CMRR of 115 dB.
