This document describes an operational amplifier with internal frequency compensation, large DC voltage gain, wide bandwidth, very low supply current/op, low input bias current, low input offset voltage, and low input offset current. It is suitable for transducer amplifiers, DC gain blocks, and all conventional op-amp circuits, which can be more easily implemented in single power supply systems.
The document provides the electrical specifications, absolute maximum ratings, and typical application circuits for the LM158, LM258, and LM358 low‑power dual operational amplifiers. It includes pin‑out diagrams, supply voltage ranges, input offset specifications, and performance graphs.
Package information for both the plastic micro‑package (SO) and the thin‑shrink small‑outline package (TSSOP) is listed, along with mechanical dimensions and recommended handling notes.
| Supply Voltage Range | 4 V to 32 V |
|---|---|
| Input Offset Voltage | 2 mV typical |
| Package (SO) | 8‑pin plastic micropackage |
| Package (TSSOP) | 8‑pin thin shrink small outline package |
The input offset voltage is typically 2 mV.
