The document introduces a product from Dinghao company, which is an EMI/EMC compliant, 15 kV ESD protected RS-232 line driver/receiver. The product features EMC compatibility, high ESD protection capability, fast transient burst immunity, low EMI emissions, etc. It also has features such as single +5V power supply, shutdown mode, and plug-in upgrade.
The ADM2xxE family provides robust RS‑232 and V.28 interface devices that operate from a single +5 V supply and meet the EU EMC Directive. They feature up to +15 kV ESD protection on all I/O pins, low‑power shutdown mode, and are offered in multiple TSSOP, SOIC, DIP and SSOP packages.
Key specifications include a guaranteed 230 kbps data rate (460 kbps for the ADM206E), shutdown supply current of 0.5 pA, and compliance with EIA‑232E and CCITT V.28. The devices are backward compatible with earlier ADM2xx parts and include shutdown and enable pins for power‑saving operation.
| Maximum Data Rate | 230 kbps (460 kbps for ADM206E) |
|---|---|
| ESD Protection (I‑O pins) | +15 kV Human Body Model |
The devices support up to 230 kbps, with the ADM206E capable of 460 kbps under specific conditions.
The I‑O pins are protected up to +15 kV Human Body Model.
