The ADV7150 (ADV®) is a complete analog output, Video RAM-DAC on a single CMOS monolithic chip. The part is specifically designed for use in high performance, color graphics workstations.
The ADV7150 is a CMOS video RAM‑DAC that provides 24‑bit true‑color output at up to 220 MHz. It integrates pixel ports, palette RAM, and on‑chip clock control for high‑performance graphics workstations.
The document lists electrical specifications, timing parameters, package information, and recommended operating conditions, making it a reference for designers implementing the chip in video and imaging systems.
| Resolution (Each DAC) | 10 Bits |
|---|---|
| Integral Nonlinearity | +1 LSB max |
| Power Supply Voltage (Vaa) | 5 V nominal |
| Ambient Operating Temperature | 0 °C to +70 °C |
| Voltage Reference Range | 1.14 V to 1.26 V |
| Package | 160‑Lead Plastic Quad Flatpack (QFP) |
The ADV7150 supports a pixel clock rate of up to 220 MHz.
The device is rated for operation from 0 °C to +70 °C.
Digital inputs require a minimum high voltage of 2 V.
It is supplied in a 160‑lead plastic quad flatpack (QFP).
