adv7152 is a 220mhz true color graphics triple 10-bit video ram-dac
The ADV7152 is a CMOS video RAM‑DAC that integrates three 10‑bit D/A converters, color palette RAM, and on‑chip clock control for high‑performance true‑color graphics. It supports multiple video modes, including 24‑bit true color at up to 220 MHz pixel clock.
The document details electrical specifications, timing characteristics, pin assignments, thermal limits, and package dimensions, helping designers implement the device in graphics workstations and imaging systems.
| Resolution (Each DAC) | 10 Bits |
|---|---|
| Integral Nonlinearity | +1 LSB max |
| Power Supply Voltage (Vaa) | 5 V nominal |
| Ambient Operating Temperature | 0 °C to +70 °C |
| Voltage Reference Range | 1.14 V to 1.26 V |
| Package | 100‑Lead Plastic Quad Flatpack (QFP) |
The ADV7152 is rated for ambient temperatures from 0 °C to +70 °C.
It operates from a 5 V nominal supply.
It is supplied in a 100‑lead plastic quad flat‑pack (QFP).
