The ISL6504 and ISL6504A complement other power building blocks (voltage regulators) in ACPI-compliant designs for microprocessor and computer applications.
The ISL6504 and ISL6504A are multiple linear power controllers with ACPI control interface, designed for microprocessor and computer applications. They integrate three linear regulators and provide four ACPI‑controlled output voltages.
The devices support 3.3 V, 5 V, 1.2 V VID and 1.5 V outputs, feature undervoltage monitoring, fault reporting, and are available in 16‑lead SOIC or 20‑lead 6×6 mm QFN packages. Absolute maximum ratings, recommended operating conditions, and detailed pin descriptions are included.
| Ambient Temperature Range | 0°C to 70°C |
|---|---|
| Maximum Junction Temperature (plastic package) | 150°C |
The maximum junction temperature for the plastic package is 150 °C.
