The ISL88694 SMBus accelerator (SMA) is a dual active pull-up bus terminator designed to improve data transmission speed on SMBus or similar 2-wire serial bus interfaces. The ISL88694 is also compatible to the I2C serial bus.
The ISL88694 is a dual‑active pull‑up bus terminator that improves data‑transmission speed on SMBus or compatible I2C interfaces. It detects rising edges, provides a boost pull‑up current for fast transitions, and reduces pull‑up current to a standby level when both lines are high to save power.
Key specifications include a wide operating voltage range of 2.7 V to 5.5 V, active pull‑up current of 275 µA, standby pull‑up current of 100 µA, boost pull‑up current of 2.2 mA, and 8 kV ESD protection on the SMBus pins. The device is offered in a 5‑lead SOT‑23 package and supports SMBus frequencies up to 100 kHz.
| Operating Voltage Range | 2.7 V to 5.5 V |
|---|---|
| Active Pull‑Up Current | 275 µA |
| Standby Pull‑Up Current | 100 µA |
| Boost Pull‑Up Current | 2.2 mA |
| Maximum SMBus Frequency | 100 kHz |
| ESD Protection | 8 kV |
| Package | 5‑lead SOT‑23 |
| Operating Temperature Range | -40 °C to +85 °C |
The device operates from 2.7 V up to 5.5 V.
The ISL88694 supports SMBus frequencies up to 100 kHz.
It offers 8 kV ESD protection on the SDA and SCL pins.
