The HIP6503 is a multiple linear power controller with an ACPI control interface. It complements either an HIP6020 or an HIP6021 in ACPI-compliant designs for microprocessor and computer applications. The IC integrates four linear controllers/regulators, switching, monitoring and control functions into a 20 pin SOIC package.
The HIP6503 is a multiple linear power controller designed for AC‑PI‑compliant microprocessor and computer applications. It integrates four linear regulators, switching, monitoring and control functions in a 20‑pin SOIC package, providing five regulated output voltages.
The document includes features, absolute maximum ratings, recommended operating conditions, electrical specifications, functional pin descriptions, timing diagrams, and a typical application circuit, along with package dimensions and ordering information.
| Supply Voltage (V5ysp) max | +7.0 V |
|---|---|
| Ambient Temperature Range | -05 °C to 70 °C |
| Maximum Junction Temperature | 150 °C |
| VCC Supply Current (nominal) | 30 mA |
| Shutdown Supply Current | 14 mA |
The maximum supply voltage is +7.0 V.
It operates from –05 °C up to 70 °C ambient temperature.
The nominal VCC supply current is 30 mA.
The shutdown supply current is 14 mA.
