Intersil ISL8843 Datasheet

ISL8843 is a single-ended current mode PWM controller from ISL company, suitable for a wide range of power conversion applications, including boost, flyback, and isolated output configurations, rated voltage 30V, operating current 90uA, rise and fall time 20ns, adjustable frequency 2MHz

Brand: Intersil
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 12
File format: PDF
File size: 293 KB
Published: 28 March, 2012
Updated: 30 September, 2023
Model: ISL8843
MD5 checksum: 9290891F8C1D7DC04749506114B9B842
PDF: Intersil ISL8843 Datasheet PDF

About this manual

The ISL8843 is a single‑ended current‑mode PWM controller designed for boost, flyback and isolated output power conversion. It offers 30 V operation, low operating current and an adjustable switching frequency up to 2 MHz.

The datasheet provides absolute maximum ratings, thermal information, detailed electrical specifications, pin descriptions, typical performance curves, and package dimensions for both SOIC and MSOP variants.

What's inside

Features
Absolute Maximum Ratings
Thermal Information
Electrical Specifications
Typical Performance Curves
Pin Descriptions
Functional Description
Soft‑Start Operation
Gate Drive
Slope Compensation

Specifications

Supply Voltage Range (Typical)	30 V operation
Adjustable Switching Frequency	up to 2 MHz

Frequently asked questions

What is the maximum switching frequency of the ISL8843?

The device can be programmed for a switching frequency up to 2 MHz.

Download PDF (293 KB)
