The X9268 is a low power, 256-tap digitally controlled potentiometer chip from Intersil. It supports 2.7V to 5.5V power supply, has 16 nonvolatile storage registers and supports multi-point storage function. Its maximum standby current is less than 5µA.
The X9268 is a dual‑supply, low‑power digitally‑controlled potentiometer featuring 256 resistor taps, a 2‑wire serial bus for read/write operations, and non‑volatile storage of wiper positions. It offers standby current below 5 µA, power‑on recall, and up to 100 yr data retention.
Typical applications include gain control in audio and RF circuits, voltage trimming in regulators, and sensor signal conditioning. The device is supplied in a 24‑lead SOIC package and is RoHS‑compliant with Pb‑free options.
| Supply Voltage Range | +2.7V to +5.5V |
|---|---|
| Standby Current | <5 µA |
| Resistor Taps | 256 |
| Wiper Resistance (typical) | 100 Ω @ V+ = 5V, V‑ = -5V |
| Non‑volatile Data Registers per Potentiometer | 16 |
| Endurance | 100,000 data changes per bit |
| Data Retention | 100 years |
| Package | 24‑lead SOIC (300 mil) |
| Operating Temperature Range | -40 °C to +85 °C |
| Resistor Versions | 50 kΩ, 100 kΩ |
The device operates from +2.7 V to +5.5 V.
It provides 256 resistor taps.
Each potentiometer has 16 non‑volatile data registers.
The standby current is less than 5 µA.
