AD9380 is a high-performance video decoder that supports HDCP and can convert HDMI signals to RGB and YCbCr signals. It supports multiple output formats and is suitable for advanced TVs, HDTVs, projectors, and LCD monitors.
The AD9380 is an 8‑bit, 150 MSPS analog‑to‑digital converter that integrates an analog video interface and an HDMI 1.1 receiver with HDCP 1.1 support. It supports both analog (RGB/Y‑Cb‑Cr) and digital HDMI/DVI inputs, providing flexible solutions for HDTVs, projectors, and LCD monitors.
The document provides full electrical specifications, absolute maximum ratings, pin‑out tables, functional block diagrams, and ordering information for the AD9380KSTZ‑100 and AD9380KSTZ‑150 package options.
| Resolution | 8 bits |
|---|---|
| HDMI Version | HDMI 1.1 |
| HDCP Support | HDCP 1.1 |
| Package Type | 100‑lead LQFP |
It includes an HDMI 1.1‑compatible receiver.
Yes, it supports HDCP 1.1 for encrypted video content.
The device requires 1.8 V and 3.3 V supply rails.
