AD9984A is a high-performance 10-bit display interface from Analog Devices, supporting a maximum conversion rate of 170 MSPS, low PLL clock jitter, automatic gain matching and automatic offset adjustment.
The AD9984A from Analog Devices is a high‑performance 10‑bit video analog‑to‑digital converter designed for HDTV, LCD monitors, projectors and graphics applications. It supports up to 170 MSPS conversion rate and includes on‑chip PLL, automatic gain matching, offset adjustment and programmable output drive strength.
The device is supplied in 80‑lead LQFP or 64‑lead LFCSP packages, operates from a 1.8 V analog supply and 3.3 V digital supply, and works over a temperature range of 0 °C to 70 °C. Detailed pin configurations, functional block diagrams and electrical specifications are provided in the document.
| Resolution | 10 bits |
|---|---|
| Maximum conversion rate | 170 MSPS |
| Analog supply voltage (Vo) | 1.8 V (typical) |
| Digital supply voltage (Vop) | 3.3 V (typical) |
| Total power dissipation | 710‑740 mW |
| Operating temperature range | 0 °C to 70 °C |
| Package options | 80‑lead LQFP or 64‑lead LFCSP |
The AD9984A can sample at up to 170 MSPS.
It is offered in an 80‑lead LQFP or a 64‑lead LFCSP package.
