AD8106/AD8107 are high speed non-blocking switch arrays with 16x5 input channels from Analog Devices. They feature excellent video performance, low power consumption and high ESD rating.
The AD8106 and AD8107 are 16 × 5 buffered video crosspoint switch matrices designed for high‑speed video routing. They operate from a +5 V supply, draw low idle current, and provide independent output buffers that can be disabled to prevent off‑channel loading.
The devices are offered in an 80‑lead LQFP package, support an operating temperature range of –40 °C to +85 °C, and include specifications such as 260 MHz –3 dB bandwidth, 5 ns propagation delay, and –78 dB crosstalk at 5 MHz.
| -3 dB Bandwidth | 260 MHz |
|---|---|
| Supply Current (outputs enabled, no load) | 30 mA |
| Operating Temperature Range | –40 °C to +85 °C |
| Output Current | 20 mA – 40 mA |
| Crosstalk (5 MHz) | –78 dB |
The devices operate from +5 V up to +45 V.
The AD8106 provides 16 inputs and 5 independent outputs.
The typical propagation delay is 5 ns.
Crosstalk is –78 dB at 5 MHz.
