The ADM6710 is a low voltage, high accuracy, triple/quad voltage microprocessor supervisory circuit that can accurately monitor up to four power supply voltages.
The ADM6710 is a low‑voltage, high‑accuracy supervisory circuit that monitors up to four power‑supply voltages. It offers five factory‑set threshold options (1.8 V, 2.5 V, 3.0 V, 3.3 V, 5 V) and adjustable thresholds down to 0.62 V, with a typical reset timeout of 200 ms.
The device is supplied in a 6‑lead SOT‑23 package and operates from –40 °C to +85 °C. It includes an open‑drain RESET output, built‑in hysteresis, and ESD protection. Typical applications include telecommunications, microprocessor systems, desktop and notebook computers, data‑storage equipment, and servers.
| Operating Voltage Range (Vee) – ADM6710Q only | 2.0 V to 5.5 V |
|---|---|
| Input Current (IN) typical | 25 µA to 40 µA |
| Reset Timeout Period (typical) | 200 ms |
| Adjustable Threshold Voltage | 0.611 V to 0.629 V |
| Operating Temperature Range | –40 °C to +85 °C |
The typical reset timeout period is 200 ms.
It provides five factory‑set threshold options: 1.8 V, 2.5 V, 3.0 V, 3.3 V, and 5 V.
The device is available in a 6‑lead SOT‑23 package.
The continuous RESET current rating is 20 mA.
