The 7B41 Rev. 0 is a signal conditioner that interfaces, amplifies, and filters unipolar and bipolar voltage inputs. The module provides a precision output of either +1V to +5V or 0V to +10V. All 7B41 series modules are mix-and-match and Hot Swappable. It is suitable for industrial signal conditioning, signal isolation, and signal filtering applications.
The 7B41 is a single‑channel signal‑conditioning module that interfaces, amplifies and filters unipolar and bipolar voltage inputs, providing a protected precision output of either +1 V to +5 V or 0 V to +10 V. It offers up to 1500 V rms continuous common‑mode isolation, high accuracy, and hot‑swappable operation for industrial process‑control environments.
The handbook includes functional block diagrams, pin‑out tables, mechanical dimensions, and a full set of electrical specifications such as non‑linearity, bandwidth, and power‑supply requirements, enabling designers to integrate the module into rack‑mount backplanes and custom instrumentation.
| Maximum nonlinearity | +0.02 % (max) |
|---|---|
| Maximum accuracy | +0.1 % (max) |
| Isolation voltage | 1500 V rms (continuous) |
| Common‑mode rejection (CMR) | 110 dB @ 50/60 Hz |
| Normal‑mode rejection (NMR) | 100 dB @ 50/60 Hz |
| Input voltage range | 0 V‑10 V (standard) |
| Output voltage range | +1 V‑+5 V or 0 V‑+10 V |
| Bandwidth (‑3 dB) | 10 Hz‑100 kHz |
| Power‑supply range | +14 VDC to +35 VDC |
| Mechanical dimensions | 1.663" × 2.11" × 0.563" (42.24 mm × 53.6 mm × 14.3 mm) |
The module provides up to 1500 V rms continuous common‑mode voltage isolation.
It operates from a nominal +24 VDC supply and accepts a range of +14 VDC to +35 VDC.
The module can output either +1 V to +5 V or 0 V to +10 V, with custom ranges also possible.
Its –3 dB bandwidth spans from 10 Hz up to 100 kHz.
