This manual covers the safe operation of the Sanyo MCD-27X100F CD portable radio cassette recorder. It includes important laser safety warnings, power‑supply precautions, and general handling guidelines.
The guide describes the device’s controls, radio tuning, CD playback, cassette recording functions, and power specifications. It also lists the technical parameters such as frequency ranges, voltage requirements, and physical dimensions.
| FM frequency range | 87.5 – 108 MHz |
|---|---|
| AM frequency range | 526.5 – 1606.5 kHz |
| Audio frequency response | 80 Hz – 12 kHz |
| AC power input | 110 V, 60 Hz |
| DC power input | 12 V |
| Maximum current consumption | 2.2 mA |
| Dimensions (W×H×D) | 300 mm × 166 mm × 265 mm |
The FM band spans from 87.5 MHz to 108 MHz.
It can be powered from an AC source of 110 V 60 Hz or from a 12 V DC supply.
The unit measures approximately 300 mm × 166 mm × 265 mm.
The recorder draws about 2.2 mA during operation.
