This document introduces the features and characteristics of the ADT7411 temperature sensor and 8-channel ADC
The ADT7411 combines a 10‑bit temperature sensor and an 8‑channel 10‑bit ADC in a 16‑lead QSOP package. It operates from a single 2.7 V to 5.5 V supply and offers both 4‑wire SPI/QSPI/MICROWIRE/DSP and 2‑wire SMBus/I²C serial interfaces. Features include a standby mode, double‑buffered input logic, and low power‑down current (<10 pA).
Typical applications are portable battery‑powered instruments, PCs, smart battery chargers, telecommunications test equipment, domestic appliances and process controls. The device is supplied in various temperature‑graded QSOP packages and an evaluation board is available.
| Supply voltage range | 2.7 V to 5.5 V |
|---|---|
| Operating temperature range | ‑40 °C to +120 °C |
| Resolution (ADC & temperature) | 10 bits (0.25 °C) |
| Power‑down current | <10 pA |
| Analog input voltage range | 0 V to 2.25 V |
| Number of analog channels | 8 |
| Conversion time (slow ADC, averaging on) | 125.4 ms |
| Power dissipation (3.3 V, normal mode) | 10 mW |
The device operates from 2.7 V to 5.5 V.
It includes an 8‑channel ADC.
The sensor offers 10‑bit resolution, equivalent to 0.25 °C.
The power‑down current is less than 10 pA.
