This document is the datasheet of AD7940, which introduces the features and characteristics of AD7940, including speed, power consumption, voltage range, bandwidth, interface, applications, etc.
The AD7940 is a 14‑bit successive‑approximation ADC that operates from a single 2.5 V to 5.5 V supply and provides up to 100 kSPS throughput. It features a low‑noise track‑and‑hold amplifier, no pipeline delays, and a serial interface compatible with SPI, QSPI, Microwire and DSP protocols. Power‑down mode reduces consumption to 0.5 pA.
Typical applications include battery‑powered systems, personal digital assistants, medical instruments and mobile communications. The device is offered in 6‑lead SOT‑23 and 8‑lead MSOP packages and includes detailed pin‑out, timing, and layout guidelines to aid PCB designers.
| Resolution | 14 Bits min |
|---|---|
| Throughput Rate | 100 kSPS max |
| Supply Voltage | 2.5 V to 5.5 V |
| Power Consumption (Normal Mode, Operational) | 26.4 mW max at 5.5 V, 100 kSPS |
| Standby Current | 0.5 pA max |
| Input Voltage Range | 0 V to Vpp |
| Available Packages | 6‑lead SOT‑23, 8‑lead MSOP |
The AD7940 can sample up to 100 kSPS.
In shutdown (standby) mode the device draws only 0.5 pA max.
It operates from a single supply of 2.5 V to 5.5 V.
The ADC is offered in 6‑lead SOT‑23 and 8‑lead MSOP packages.
