This manual introduces the features and functions of the ASUS P5VD2-X motherboard, including installation, configuration, and maintenance.
This manual covers everything needed to install and configure the ASUS P5VD2-X motherboard, including hardware setup, jumper settings, connector descriptions, and detailed BIOS configuration. It also explains the contents of the support CD, RAID utilities, and driver creation.
Safety guidelines, FCC compliance information, and troubleshooting tips are included, along with a specifications summary that lists CPU socket, chipset, memory, expansion slots, storage, audio, LAN, and USB capabilities.
| CPU socket | LGA775 for Intel Core2 / Pentium D / Pentium 4 / Celeron |
|---|---|
| Chipset | Northbridge VIA PT890, Southbridge VIA VT8237A |
| Memory | 2 x 240‑pin DIMM sockets, up to 4 GB DDR2 533 unbuffered non‑ECC |
| Expansion slots | 1 PCI‑Express x16, 1 PCI‑Express x1, 4 PCI slots |
| Storage interfaces | 1 internal SATA 3 Gb/s, 1 external SATA 3 Gb/s, RAID 0/1/JBOD |
| Audio codec | Realtek ALC883 6‑channel high‑definition audio |
| LAN controller | Realtek RTL8110SC Gigabit Ethernet |
| USB ports | Up to 8 USB 2.0 ports |
In the JMB363 RAID BIOS menu select Delete RAID Disk Drive, choose the set, and confirm with
Disconnect the power cable from the outlet, ensure all power cables are unplugged before handling connectors, and avoid short‑circuit hazards.
Highlight Save & Exit Setup in the BIOS menu and press
Insert the motherboard support CD, select the RAID driver utility, and follow the prompts to write the driver to a floppy disk.
