ASUS P5VD2-VM/P5V-VM SE DH Motherboard User Manual

This is a user manual for P5VD2-VM/ P5V-VM SE DH ii motherboard

Brand: ASUS
Category: Other Computer Accessories
Document type: User Manual
Language: English
Pages: 110
File format: PDF
File size: 1.9 MB
Published: 22 March, 2012
Updated: 30 September, 2023
Models: P5V-VM, P5VD2-VM
MD5 checksum: 1ACB0C67D7964CF4555A49FE7C3A1A96
PDF: ASUS P5VD2-VM/P5V-VM SE DH Motherboard User Manual PDF

About this manual

This manual guides users through installing and configuring the ASUS P5VD2-VM/P5V-VM SE DH motherboard, covering hardware setup, safety precautions, and connector details.

It also explains BIOS configuration, RAID setup, software support, and lists the technical specifications such as CPU socket, chipset, memory, expansion slots, and integrated peripherals.

What's inside

Product introduction
Safety information
BIOS setup
Software support
Specifications summary
RAID configuration
Installation procedures
Connector overview

Specifications

CPU socket	LGA775
Northbridge chipset	VIA P4M900
Southbridge chipset	VIA VT8237A
Memory slots	2 × 240‑pin DIMM, up to 4 GB DDR2 667/533
Expansion slots	1 × PCI Express x16, 1 × PCI Express x1, 2 × PCI
Integrated graphics	VGA, up to 256 MB shared memory
Storage interfaces	2 × Ultra DMA 133/100/66/33, 2 × Serial ATA (RAID 0/1/JBOD)
Audio codec	ADI® AD1986A SoundMax 5.1‑channel
LAN controller	Realtek® RTL8110SC Gigabit
USB ports	Up to 8 × USB 2.0

Frequently asked questions

How do I delete a RAID set on the P5VD2-VM/P5V-VM SE DH motherboard?

In the JMB363 RAID BIOS menu, highlight the RAID set, press ~~to delete it, then confirm with .~~

What safety steps should I take before installing the motherboard?

Disconnect the power cable from the outlet before relocating or installing the system and ensure all cables are unplugged before connecting components.

How many USB ports are available on this motherboard?

The motherboard supports up to eight USB 2.0 ports.
