This document is the DCS 600 CraneDrive system description document of Siemens (SIEMENS) company. The document details the composition, environmental conditions, power conversion modules, overload capacity, power supply, options, line reactor and other information of DCS 600 CraneDrive.
The DCS 600 CraneDrive is a modular power converter designed for crane applications, offering speed and torque control for DC motors. The manual provides a complete overview of the system, including component descriptions, environmental limits, and wiring diagrams.
It also details the software functions, control interfaces, and commissioning tools such as the DriveWindow PC program and CDP 312 control panel, enabling installation, configuration, and maintenance of the drive system.
| Power range | 10…500 kW (13…670 HP) |
|---|---|
| Input voltage | 230 V to 1000 V (3‑phase) |
| IP rating | IP 20/21/31/41 |
| Ambient temperature range | 0 °C to +55 °C |
Five sizes are offered: C1, C2, A5, A6 and A7.
