This manual introduces the ACS 600 series products, including ACS 604 and ACS 6x7, of which ACS 604 is a single-phase switchgear and ACS 6x7 is a three-phase switchgear. Both switchgears adopt modular design, with high reliability, high safety and high electrical performance
This manual provides comprehensive safety instructions for the ABB ACS600 variable‑frequency drive series, covering hazards, required protective measures and warnings to prevent personal injury or equipment damage. It also details the proper installation procedures, including wiring, grounding and EMC filtering requirements.
Additional sections describe operating procedures, emergency‑stop wiring, ground‑fault protection settings and the technical specifications such as power range, voltage ratings and du/dt limits, enabling technicians to configure and maintain the drive safely and efficiently. This manual is written in Chinese.
| Power rating | 55 to 630 kW |
|---|---|
| Power rating (alternative) | 75 to 700 kW |
The manual warns that improper operation can cause personal injury or death and that all work must follow the safety regulations.
The drive permits a maximum of 10 start attempts, with no more than 5 attempts within a short period.
Use a multimeter to measure the resistance of the input terminals before connecting power.
