This manual begins with safety warnings, including the 7‑year environmental service life and precautions against electric shock, water damage and dust. It also lists the required accessories and contact information for TCL customer service.
The guide then describes the TV’s key features, technical specifications, remote‑control functions, basic and advanced operations (such as automatic and manual channel search, image and sound adjustments, and game mode), and a troubleshooting section for common picture and sound issues. This manual is written in Chinese.
| Screen size (diagonal) | 68 cm |
|---|---|
| Power consumption | 70 W |
| Rated voltage / frequency | 220 V ~ 50 Hz |
| Dimensions (W×D×H) | 784 × 531 × 601 mm |
| Weight | ≈35 kg |
| RF antenna input | 75 Ω (VHF/UHF) |
| AV input audio level | 0.5 V rms |
| AV output audio level | 0.5 V rms |
| Audio output power | 5 W + 5 W |
Press the TV’s MENU/SEARCH key for three seconds to enter automatic search mode, or use the remote’s MENU key, then select the SEARCH submenu and confirm.
Open the battery cover on the remote, insert two 7‑cell 1.5 V batteries with the correct polarity, and close the cover.
