This manual provides safety warnings, installation instructions, and detailed operation guidance for TCL televisions. It includes diagrams of the front panel, remote control, and connection ports, as well as menu navigation and picture settings.
Technical specifications such as supported video formats, input interfaces, power requirements, and environmental limits are listed, followed by a fault analysis section that helps diagnose common issues like no picture, no sound, or interference. This manual is written in Chinese.
| Operating voltage | 220V~ 50Hz |
|---|---|
| Operating temperature | 5°C‑35°C |
| Operating humidity | 20%‑80% |
| Supported video modes | SDTV and HDTV (480i/576i/p, 720p, 1080i/p) |
| Input interfaces | AV, YPbPr, VGA, HDMI, USB |
| Channel reception range | 470 MHz (full‑band cable TV) |
Check that the power cable is plugged in, the power switch is on, the remote’s batteries are correctly installed, and that the TV is not in mute mode.
Verify the signal source, adjust the antenna or cable connection, and ensure the correct input source is selected.
