This document is the user manual for SyncMaster 943NW/943NWX LCD monitor, providing information on safety instructions, installation, and cleaning of the monitor.
This manual covers safety instructions, proper installation, and handling of the SyncMaster 943NW/943NWX LCD monitor. It explains how to avoid hazards, mount the unit safely, and maintain the display for reliable operation.
The guide also details initial configuration, button functions, display settings, and technical specifications such as screen size, resolution, and power requirements. Service and warranty information are provided for troubleshooting and support. This manual is written in Chinese.
| Screen size | 19 inches (48 cm) |
|---|---|
| Display area | 408.24 mm × 255.15 mm |
| Dot pitch | 0.2835 mm (H) × 0.2835 mm (V) |
| Horizontal sync | 30–81 kHz |
| Vertical refresh rate | 56–75 Hz |
| Native resolution | 1440 × 900 @ 60 Hz |
| Maximum resolution | 1440 × 900 @ 75 Hz |
| Input signal | RGB analog 0.7 Vp‑p ±5 % |
| Maximum pixel clock | 137 MHz |
| Power supply | AC 100‑240 V, 50/60 Hz |
| Dimensions (without stand) | 439 × 290 × 68.4 mm |
Place your eyes about 45–50 cm from the screen, with the line of sight slightly above the display.
Press the brightness button (marked [ ]) when the OSD is not displayed to change the brightness level.
