This document is the safety instructions manual for the Samsung SyncMaster 2343BW/2343BWX LCD monitor. The document describes safety precautions to be taken when using the monitor.
This manual covers essential safety instructions, proper installation steps, and cleaning procedures for the 23‑inch SyncMaster 2343BW/2343BWX LCD monitor. It emphasizes correct power handling, ventilation, and handling to prevent injury or damage.
Technical details such as display size, resolution, input options, power requirements, and dimensions are listed, along with warranty information and service contacts for Samsung. This manual is written in Chinese.
| Display size | 23 inches (58 cm) |
|---|---|
| Display area | 50.995 cm × 28.685 cm |
| Dot pitch | 0.249 mm × 0.249 mm |
| Horizontal sync frequency | 30 ~ 75 kHz |
| Vertical refresh rate | 56 ~ 61 Hz |
| Colors | 16.7 million |
| Maximum resolution | 2048 × 1152 @ 60 Hz |
| Input signals | RGB analog, DVI digital |
| Maximum pixel clock | 157 MHz |
| Power supply | AC 100‑240 V, 50/60 Hz |
| Dimensions (without stand) | 54.46 × 32.31 × 7.29 cm |
Immediately unplug the power cord and contact the service center, as the manual advises.
