C.915PD2 Ver2.3 is a motherboard designed with Intel 915P+ICH6 chipset, supports Intel Socket 775 Prescott/Cedar Mill core Pentium 4/Celeron D series processors; supports 533/800MHz FSB system bus; supports dual-channel DDR 266/333/400MHz and DDR2 400/533 storage architecture; supports the new generation PCIE x16 graphics card interface; Onboard 6 channel audio; integrated RTL8100C 100M network card.
This manual introduces the Colorful C.915PD2 Ver2.3 motherboard built on the Intel 915P+ICH6 chipset, supporting Intel Socket 775 Pentium 4/Celeron D processors, dual‑channel DDR and DDR2 memory, PCI Express x16, SATA, USB 2.0 and integrated Realtek audio and RTL8100C Ethernet.
It provides detailed hardware installation procedures, BIOS configuration options, connector descriptions, error‑code diagnostics and BIOS update instructions, helping users assemble, configure and maintain the system safely. This manual is written in Chinese.
| Chipset | Intel 915P+ICH6 |
|---|---|
| Memory Slots | 2×184‑pin DDR (266/333/400 MHz) + 2×240‑pin DDR2 (400/533 MHz) |
| Expansion Slots | 1×PCI‑Express x16, 2×PCI‑Express x1, 3×PCI |
| USB Ports | 8×USB2.0 (compatible with USB1.1) |
| LAN Controller | Realtek RTL8100C 10/100 Mbps |
| Audio Codec | Realtek RLC655 AC97 v2.2 |
It signals a keyboard controller error; the motherboard should be checked.
No, DDR1 and DDR2 modules cannot be installed simultaneously.
Power off, unplug the ATX power, short pins 1‑2 of the JCS2 jumper for 3 seconds, then restore the jumper to 2‑3.
