This manual provides detailed instructions on how to use i Motherboard, including installation, disassembly, configuration, and wiring.
This manual provides step‑by‑step instructions for installing the PCCHIPS P55G Series motherboard, including static‑electricity precautions, component identification, CPU and memory installation, jumper settings, and connecting optional devices. It also describes the BIOS setup utility, power‑management options, and integrated peripherals.
Additional sections cover bundled software installation, optional accessories, and troubleshooting tips for Windows operating systems. Technical specifications such as supported processors, memory types, expansion slots, and I/O ports are listed throughout the guide.
| CPU socket | LGA775 |
|---|---|
| Supported processors | Intel Core 2 Quad/Duo, Pentium D/4, Celeron D |
| Front‑Side Bus | Up to 1333 MHz (over spec) |
| Chipset | NVIDIA MCP73V |
| Memory type | DDR2 SDRAM, up to 4 GB |
| Memory speed | DDR2‑667/533 (over spec up to 800 MHz) |
| Form factor | Micro ATX (244 × 194 mm) |
| Expansion slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1, 2 × 32‑bit PCI |
| Audio | 6‑channel DAC, 16/20/24‑bit PCM, 5.1 support |
It uses an LGA775 socket for Intel processors.
It is a Micro ATX board measuring 244 × 194 mm.
The motherboard integrates the NVIDIA MCP73V single‑chip chipset.
