L32N51TC is a 32-inch LCD TV from LeEco. It supports VGA interface, DVD playback, AV interface, PC interface, CATV interface, and AV2 interface.
This manual covers safety warnings, environmental usage limits, and the main accessories supplied with the TCL L32N5 liquid‑crystal television. It explains the TV’s functions, image and sound settings, and the remote‑control layout.
Installation instructions detail how to connect antenna, HDMI, component, and audio/video cables, as well as how to adjust picture modes, aspect ratios, and volume. Technical specifications and quick‑operation shortcuts are listed, followed by a troubleshooting guide for common issues such as no picture or no sound. This manual is written in Chinese.
| Audio Output Power | 8W + 8W (left + right) |
|---|---|
| Operating Voltage | 100‑240 V, 50/60 Hz |
| Screen Diagonal | 80 cm |
| Unit Dimensions (W×H×D) | 800 mm × 560 mm × 100 mm |
| Unit Weight with Stand | ≈15.2 kg |
| Stand Weight | ≈4.2 kg |
Check that the power is on, the antenna or cable is properly connected, and the selected input source is correct.
Press the Image Mode button on the remote control to cycle through the available picture modes.
Use an HDMI cable to connect the HDMI output of the source device to the TV’s HDMI input port.
