This datasheet provides details of Maxim DG508A/DG509A, including applications, features, etc.
The Maxim DG508A and DG509A are monolithic CMOS analog multiplexers offering 8‑channel single‑ended (DG508A) and 4‑channel differential (DG509A) operation. They feature break‑before‑make switching, latch‑up‑proof construction, and low power consumption, making them suitable for portable equipment and data‑logging applications.
The datasheet provides absolute maximum ratings, electrical characteristics, pin configurations, package options, and timing diagrams. It also lists ordering information, temperature ranges, and revision history for the devices.
| Supply Voltage Range | ±4.5 V to ±18 V |
|---|---|
| Operating Temperature Range (DG508AAK / DG509AAK) | -55 °C to +125 °C |
The devices operate from ±4.5 V up to ±18 V.
