The manual provides step‑by‑step instructions for installing and configuring the DR‑S0833/DR‑S1633 digital recorder, including hardware connections, system settings, and network remote viewing. It also details safety warnings, FCC/Canadian compliance, and troubleshooting guidelines.
Key sections cover hardware front‑panel layout, rear connector functions, RS‑232/485 control, PTZ camera integration, recording and playback options, backup to USB/CD‑RW, and power consumption specifications.
| Video input channels | BNC × 8 / BNC × 16 |
|---|---|
| Video output | BNC × 1 |
| Audio input | RCA × 1 |
| Audio output | RCA × 1 |
| Dimensions (W×H×D) | 430 mm × 91 mm × 380 mm |
| Maximum recording speed (320×240) | up to 120 PPS |
The recorder supports either 8 BNC video inputs or 16 BNC video inputs.
The device supports up to two IDE hard drives (one removable) and can back up to CDRW or USB devices.
