This document is about the instruction manual for a product, which mainly introduces the product's key panel, rear interface, function settings, operating procedures, etc.
The Sampo DR‑S0424 recorder manual explains how to operate the device, covering menu navigation, recording modes, playback functions, hard‑drive management, and alarm settings. It also details hardware connections such as camera inputs, monitor outputs, Ethernet, and COM‑port interfaces.
The document includes step‑by‑step instructions for configuring recording resolutions (e.g., 720×480 NTSC, 720×576 PAL), selecting record modes (MUX, QUAD), managing storage devices (hard drive, CF card), and adjusting system parameters like date/time and passwords. This manual is written in Chinese.
| Recording resolution (NTSC) | 720×480 |
|---|---|
| Recording resolution (PAL) | 720×576 |
| Recording resolution (NTSC low) | 640×224 |
| Recording resolution (PAL low) | 640×272 |
| Supported hard‑drive capacities | 40 GB – 250 GB |
Enter the MASTER HARD DRIVE menu, then adjust the date and time fields.
