This manual covers safety regulations, precautions before use, and detailed descriptions of each component and remote controller functions. It also includes installation guidelines such as pipe connections, electrical wiring, and recommended indoor‑unit mounting height.
The second part explains normal operation, timer settings, sleep mode, air‑flow direction, maintenance procedures, and a troubleshooting guide with test‑run instructions. Technical specifications for both indoor and outdoor units are listed at the end. This manual is written in Japanese.
| Indoor unit dimensions (WxHxD, mm) | 1150 x 300 x 260 |
|---|---|
| Outdoor unit dimensions (WxHxD, mm) | 950 x 800 x 300 |
The power cord uses a Y‑type connector; if it is damaged, contact Sampo service personnel for replacement and do not replace it yourself.
The indoor unit should be installed at a height of at least 2.5 m to ensure proper operation.
