This manual provides safety warnings, component identification, and step‑by‑step installation instructions for the Haier KMR‑22Q commercial air‑conditioning unit. It explains how to connect power, mount the indoor and outdoor units, install filters, and perform initial commissioning.
The guide also includes operating instructions for the remote and wired controllers, clock calibration, battery replacement, and a technical data table with cooling/heating capacities, power consumption, voltage, current, weight and airflow specifications. This manual is written in Chinese.
| Cooling capacity | 5600W |
|---|---|
| Heating capacity | 6300W |
| Power consumption (cooling) | 100W |
| Power consumption (heating) | 100W |
| Voltage | 220V~ 50Hz |
Press the clock key, then adjust the time using the up/down buttons; hold the button for rapid change, and confirm with the set key.
When the filter warning appears, remove the filter, clean it, and press the filter reset key before the unit can operate again.
