This manual introduces the safety warnings and precautions of Lenovo ThinkServer servers, including electrostatic discharge (ESD) and ESD protection, heat dissipation and ventilation, and scope of use.
This manual provides safety warnings, product overview, technical specifications, and configuration guidance for the Lenovo R510 G5 1U rack server. It is intended for professional technicians and experienced users who install, configure, and maintain the system.
The document includes detailed sections on hardware architecture, BIOS and RAID settings, operating‑system installation procedures for SCSI and SATA, as well as a troubleshooting FAQ and appendices on networking and VLAN technology. This manual is written in Chinese.
| Cache | 2 MB |
|---|---|
| Memory type | Registered ECC DDRII400 SDRAM |
| Maximum memory capacity | 8 GB |
| SCSI controller | Ultra320 SCSI |
| Network interfaces | 2 × Gigabit Ethernet ports |
| Power supply | 500 W single PSU |
| Dimensions (H × W × D) | 43.5 mm × 430 mm × 690 mm |
| Weight | 13 kg – 16 kg |
The server is designed for 180 V – 240 V AC power.
It has four DIMM slots and supports up to 8 GB of memory.
The server includes two built‑in Gigabit Ethernet ports.
